康華爾電子成立至今已有20多年,是國內數一數二的晶振廠家0755-27838351,專業研發生產銷售石英晶振,32.768K晶振,石英晶體諧振器,貼片晶振,SAW濾波器等.采用無鉛環保材料生產,具有精度穩定,小體積,重量輕等特點.國產晶振就選康華爾電子,質量好,精度高,價格優勢.
康華爾電子多年來在競爭激烈的市場中,以技術占領市場,以質量贏得客戶,是國內口碑極高的晶振供應商.并且憑借自身的努力代理臺灣進口晶振多個品牌,TXC晶振,鴻星晶振,加高晶振,亞陶晶振等.康華爾電子所提供的臺產晶振,均符合德國ROHS環保指令,具有高質量,高可靠使用特性,咨詢選購熱線0755-27838351.
日本進口晶振在國內口碑一流,高端智能產品使用晶振大都會選擇日產晶振作為首選.康華爾電子憑借自身的努力同時代理KDS晶振,愛普生晶振,精工晶體,京瓷晶振等品牌.所代理石英晶振,石英晶體振蕩器,貼片晶體均符合歐盟ROHS環保要求,具有高精度,高品質,低插損,耐高溫等特點.
康華爾電子是國內優秀的歐美進口晶振供貨商0755-27838351,多年來憑借自身的努力,獲得CTS晶振,FOX晶振,Sitime晶振,瑞康晶振等代理權限.所代理進口晶振,歐美晶振均符合歐盟ROHS環保指令,并且獲得ISO國際質量管理體系認證.市場常用進口晶振封裝型號康華爾電子均有備貨,可免費提供現貨樣品以及晶振技術解決方案.
32.768K是晶振頻率中最容易讓人記住的數字,32.768K晶振素來有時鐘晶振的稱謂,只要跟數字顯示以及時間相關的產品都少不了一款32.768K晶振.根據不同的產品需求主要分為圓柱晶振和32.768K貼片晶振.常見封裝有2x6,3x8,7.0x1.5,3.2x1.5,2.0x1.2等體積.康華爾電子提供各種32.768K晶振,音叉表晶,價格優質,咨詢熱線0755-27838351.
有源晶振是一款自身帶有電源電壓功能的石英晶體振蕩器,并且有多種電壓供選擇,比如有1.8V,2.5V,3.3V,3.8V,5V等高速自動安裝和高溫回流焊設計,Optionable待機輸出三態輸出功能,電源電壓范圍：1.8V~5 V,高穩定性,低抖動,低功耗,主要應用領域:無線通訊,高端智能手機,平板筆記本WLAN,藍牙,數碼相機,DSL和其他IT產品的晶振應用,三態功能,PC和LCDM等高端數碼領域,符合RoHS/無鉛.
愛普生公司自成立以來,一直誠信經營,同時又本著誠信的核心價值觀開展業務，這是一家非常重視承諾和創新的制造商。秉持著專注，認真對待每一款產品，匠心打造優質的石英晶體產品線，作為一個致力于保護人類的全球貿易企業權利，我們認真對待防止現代奴隸制在我們的商業和供應鏈中的責任。我們致力維持最佳做法，并保持警覺，不斷作出改善.為何說EPSON的多樣性激發創新的優異石英晶振呢X1E0002510126
                           Product Number
|
 LxWxH
|
 Model
|
 Frequency
|
 CL Value
|
 Freq.tol. @+25°C
|
| X1E000411000800 | 1.2 x 1 x 0.3mm | FA1210AN | 32.000000 MHz | 8 pF | +/-10 ppm |
| X1E000411001000 | 1.2 x 1 x 0.3mm | FA1210AN | 32.000000 MHz | 8 pF | +/-10 ppm |
| X1E000411001200 | 1.2 x 1 x 0.3mm | FA1210AN | 32.000000 MHz | 8 pF | +/-10 ppm |
| X1E000251000900 | 1.6 x 1.2 x 0.35mm | FA-118T | 27.120000 MHz | 10 pF | +/-30 ppm |
| X1E000251001100 | 1.6 x 1.2 x 0.35mm | FA-118T | 26.000000 MHz | 8 pF | +/-10 ppm |
| X1E000251001400 | 1.6 x 1.2 x 0.35mm | FA-118T | 26.000000 MHz | 9 pF | +/-10 ppm |
| X1E000251001600 | 1.6 x 1.2 x 0.35mm | FA-118T | 37.400000 MHz | 16 pF | +/-10 ppm |
| X1E000251003100 | 1.6 x 1.2 x 0.35mm | FA-118T | 37.400000 MHz | 16 pF | +/-7 ppm |
| X1E000251003200 | 1.6 x 1.2 x 0.35mm | FA-118T | 40.000000 MHz | 10 pF | +/-10 ppm |
| X1E000251003300 | 1.6 x 1.2 x 0.35mm | FA-118T | 25.000000 MHz | 10 pF | +/-30 ppm |
| X1E000251003400 | 1.6 x 1.2 x 0.35mm | FA-118T | 25.000000 MHz | 9 pF | +/-30 ppm |
| X1E000251003500 | 1.6 x 1.2 x 0.35mm | FA-118T | 30.000000 MHz | 8 pF | +/-20 ppm |
| X1E000251004600 | 1.6 x 1.2 x 0.35mm | FA-118T | 24.000000 MHz | 12 pF | +/-10 ppm |
| X1E000251005000 | 1.6 x 1.2 x 0.35mm | FA-118T | 32.000000 MHz | 9 pF | +/-10 ppm |
| X1E000251005600 | 1.6 x 1.2 x 0.35mm | FA-118T | 52.000000 MHz | 9 pF | +/-15 ppm |
| X1E000251005700 | 1.6 x 1.2 x 0.35mm | FA-118T | 25.000000 MHz | 7 pF | +/-30 ppm |
| X1E000251005900 | 1.6 x 1.2 x 0.35mm | FA-118T | 32.000000 MHz | 8 pF | +/-10 ppm |
| X1E000251006000 | 1.6 x 1.2 x 0.35mm | FA-118T | 48.000000 MHz | 10 pF | +/-30 ppm |
| X1E000251006400 | 1.6 x 1.2 x 0.35mm | FA-118T | 26.000000 MHz | 12 pF | +/-10 ppm |
|
Product Number
|
LxWxH
|
Model日產晶振
|
Frequency
|
CL Value
|
Freq.tol. @+25°C
|
| X1E000411000800 | 1.2 x 1 x 0.3mm | FA1210AN | 32.000000 MHz | 8 pF | +/-10 ppm |
| X1E000411001000 | 1.2 x 1 x 0.3mm | FA1210AN | 32.000000 MHz | 8 pF | +/-10 ppm |
| X1E000411001200 | 1.2 x 1 x 0.3mm | FA1210AN | 32.000000 MHz | 8 pF | +/-10 ppm |
| X1E000251000900 | 1.6 x 1.2 x 0.35mm | FA-118T | 27.120000 MHz | 10 pF | +/-30 ppm |
| X1E000251001100 | 1.6 x 1.2 x 0.35mm | FA-118T | 26.000000 MHz | 8 pF | +/-10 ppm |
| X1E000251001400 | 1.6 x 1.2 x 0.35mm | FA-118T | 26.000000 MHz | 9 pF | +/-10 ppm |
| X1E000251001600 | 1.6 x 1.2 x 0.35mm | FA-118T | 37.400000 MHz | 16 pF | +/-10 ppm |
| X1E000251003100 | 1.6 x 1.2 x 0.35mm | FA-118T | 37.400000 MHz | 16 pF | +/-7 ppm |
| X1E000251003200 | 1.6 x 1.2 x 0.35mm | FA-118T | 40.000000 MHz | 10 pF | +/-10 ppm |
| X1E000251003300 | 1.6 x 1.2 x 0.35mm | FA-118T | 25.000000 MHz | 10 pF | +/-30 ppm |
| X1E000251003400 | 1.6 x 1.2 x 0.35mm | FA-118T | 25.000000 MHz | 9 pF | +/-30 ppm |
| X1E000251003500 | 1.6 x 1.2 x 0.35mm | FA-118T | 30.000000 MHz | 8 pF | +/-20 ppm |
| X1E000251004600 | 1.6 x 1.2 x 0.35mm | FA-118T | 24.000000 MHz | 12 pF | +/-10 ppm |
| X1E000251005000 | 1.6 x 1.2 x 0.35mm | FA-118T | 32.000000 MHz | 9 pF | +/-10 ppm |
| X1E000251005600 | 1.6 x 1.2 x 0.35mm | FA-118T | 52.000000 MHz | 9 pF | +/-15 ppm |
| X1E000251005700 | 1.6 x 1.2 x 0.35mm | FA-118T | 25.000000 MHz | 7 pF | +/-30 ppm |
| X1E000251005900 | 1.6 x 1.2 x 0.35mm | FA-118T | 32.000000 MHz | 8 pF | +/-10 ppm |
| X1E000251006000 | 1.6 x 1.2 x 0.35mm | FA-118T | 48.000000 MHz | 10 pF | +/-30 ppm |
| X1E000251006400 | 1.6 x 1.2 x 0.35mm | FA-118T | 26.000000 MHz | 12 pF | +/-10 ppm |
愛普生公司推出高可靠性能和耐壓性能的FA-118T，編碼是X1E0002510126，這是一款超小型的SMD晶振,無源晶振，頻率為24.000000兆赫，尺寸(長×寬×高)1.6 × 1.2 × 0.35 mm，客戶負載電容7pf，頻率公差+ / -30 ppm，Fo / temp。特征公差+ / -30 ppm，溫度范圍-20到+75°C，ExtraOptionsN /，運動阻力(最大)200 Ω，型號名稱產品名稱useFA-118T
驅動水平(最大)100µW，頻率老化+ / 5 ppm，泛音orderFundamental.
